Electromechanical Equipment Supply For 2x275KW Mini Hydro Power Plant

Dongturbo Electric Company Ltd is one of the leading manufacturers and suppliers of electromechanical equipment supply for 2x275kw mini hydro power plant in China. We warmly welcome you to buy high quality customized products at competitive price from our factory. Contact us for more cheap products.

. Hydraulic Turbine and Accessories:

Hydraulic Turbine 2 nos. @275 kW Horizontal Pelton type tangential flow impulse turbines double jet with inlet valve, casing, guide vanes,, with associated auxiliary and ancillary equipments in complete set to develop rated output of 275 kW(mechanical) at rated net head and rated discharge with 10% Contineous Over Loading (COL) Turbine Casing with Stay vans, foundation materials all complete with accessories Transition pipe with all complete accessories Wicket gate or Guide Vane assembly with accessories Side Cover, Labyrinth seal, shaft seals, etc. with accessories Turbine Generator shaft coupling system all complete. Fly wheel complete with protection system

. Inlet Valve:

2 Lot, Main Inlet Valve with hydraulic operated and closing by counter weight, branch pipe to connect with penstock and turbine with necessary control & operation arrangements, fittings, mountings and other ancillary equipment’s in complete set.Electric Motor Operated,Nominal Dia(DN):300 mm, Nominal Pressure(PN): 16MPa.

. Governing System:

2 Lot, Digital Speed Governing equipment with oil pressure system, actuator, servomotor, pipings, mountings, safety devices, hand wheel, motors, fittings, water level sensor complete set with PLC from reputable manufacturer with a rated pressure of 16 MPa.

. Synchronous Generator:

2 Lot ; with rating of 350 kVA , 0.4kV, 3 phase, 0.8 pf, 50 Hz ±3%, class 'F' insulation, brussless excitation, terminal equipment like neutral grounding system, CT's, PTs, LA/SC and other auxiliary system with contineous duty and 10% contineously overload capacity.

. Auxillary equipment Electrically Operated Travelling(EOT) ; 1 Lot; crane 10 t system complete with accessories Fire fighting System all complete ; 1 Lot Illumunation and Ventilating System ; 1 set

. Control Panel ; 2 Lot

. Outdoor Switchyard Equipment: 1 Lot

. Storage Battery and Battery Charger : 1 Lot
